Aerosense Series ASOS-818-CM Occupancy Sensor
Product Applications:
- Lighting control
- Building energy conservation
Series ASOS-818-CM, Occupancy Sensor
Series ASOS-818-CM, passive infrared Occupancy sensor automatically controls a HVAC ventilation system. It is a low cost commercial and residential surface mount occupancy sensor. Advanced filtering reduces false triggering due to air movement and lighting changes. The spherical Fresnel lens provides a 360˚ detection zone with the use of infrared technology.
MAIN FEATURES
- Intelligent logic control, anti false alarm efficiently -Auto temperature compensation
- Pulse count adjustment -Anti white light interference -Anti RF interference (20V/m-1GHz)
- Fresnel lens
- ceiling installation
- SMT design adopted -Alarm output N.C./N.O., Anti RF Interface
TECHNICAL SPECIFICATION
- Operating voltage: 12VDC / 24 VAC Current consumption: <18mA (24VAC)
- Detecting distance: Diameter 8m (when height is 3.6m) Detecting angle:360°
- Self-testing time: about 60S
- Operating temperature: -10~+50 °C
- Alarm indicator: red LED
- Alarm output: N.C.or N.O., DC28V, 100mA
- Tamper output: N.C., DC28V, 100mA
- Range of coverage: 24 distance, 24 middle, 6 vicinities
- Sensor: dual element infrared sensor
- Operating temperature: -10 ~ +50 °C
- Environment humidity: 95%RH (non condensing)
- Anti RF interference: 10MHz ~ 1GHz 20V/m Installation mode: ceiling mounted Installation height: 2.5 ~ 6m Outline Size: 106(Dia.) * 36(Thickness) mm
