Aerosense Series ASOS-818-SM, Occupancy Sensor
Product Applications:
- Lighting control
- Building energy conservation
Series ASOS-818-SM, Occupancy Sensor
Series ASOS-818-SM, passive infrared Occupancy Sensor is a low cost commercial and residential surface mount occupancy sensor. Advanced filtering reduces false triggering due to air movement and lighting changes. The sensor switches a dry contact which is wired to a separate controller. There is a tamper switch terminal as well, when the enclosure is opened up the central controller will be able to signal an alert.
MAIN FEATURES
- Intelligent logic control, anti false alarm efficiently -Auto temperature compensation
- Pulse count adjustment -Anti white light interference
- Anti RF interference (20V/m-1GHz)
- Fresnel lens
- Wall installation
- SMT design adopted
- Alarm output N.C./N.O. Optional
TECHNICAL SPECIFICATION
- Operating voltage: 12VDC / 24 VAC
- Current consumption: <18mA (24VAC)
- Detecting distance: 12m Detecting angle:110°
- Self-testing time: about 60S
- Operating temperature: -10~+50 °C
- Alarm indicator: red LED
- Alarm output: N.C.or N.O., DC28V, 100mA
- Anti dismantle output: N.C., DC28V, 100mA
- Range of coverage: 11 distance, 8 middle, 5 vicinities
- Sensor: dual element infrared sensor
- Operating temperature: -10 ~ +50 °C
- Environment humidity: 95%RH (non condensing)
- Anti RF interference: 10MHz ~ 1GHz 20V/m
- Installation mode: wall mounted or hanged in corner Installation height: 1.7 ~ 2.5m (2.2m is Proposed)
- Outline Size: 59(L) * 39.5(W) * 107(H) mm
